Surge Guards

--------------------------------------------------

30 AMP Surge Guard (Hardwired) - $261.09 (Part Only), $477.72 (Part plus Installation)
120V, 2450 Joules, Model 35530

35530

This NEW 30 amp Surge Guard product monitors shore power continuously and shuts off when it detects power surges, open ground, open neutral, low or excessive voltage, mis-wired pedestals, or reverse polarity that could damage electronic equipment in your coach.  The 30 amp hardwire is permanently installed within the bay of your coach, preventing potential theft and damage from the elements. Optional Remote LCD Display conveniently and remotely monitors RV electrical power.

Additional model 35530 features include: Usage

  • Automatic reset on power restoration.
  • Multi-mode surge suppression
  • Automatically shuts off the power when the following is present:
    • Open ground
    • Open neutral
    • Low (<102V) and High (>132V) Voltage
    • Miswired pedestal
    • Reverse polarity
  • Caution indicator light indicates:
    • Elevated ground voltage
    • Surge failure indication
  • 128 second reset delay protects A/C compressor
  • 2450 Joules of power surge protection
  • Easy installation
  • Optional Remote Power Monitor LCD Display, p/n 40300, (sold separately)
    • Plugs into remote port on Surge Guard model 35530 (see above)
    • Compatible with previous models with a telecom jack
    • 16 Detailed Fault Screens
    • Joystick for easy screen navigation
    • Plug and Play (cable included)

--------------------------------------------------

30 AMP Portable Surge Guard - $293.19
120V, 2450 Joules, Model 34830

34830

The new 30 Amp Surge Guard portable with LCD display offers more than twice the Joules of power surge protection than the previous model. Continuously monitors for voltage and amp draw and reverse polarity (miswired pedestal, elevated ground voltage). Compact and easy to use, they plug in between the power pedestal and the line cord to provide protection. Designed for all travel trailers, 5th wheels and motorhomes with 30 Amp service.

  • Protects RV from faulty park power
  • Built-in intelligence
  • Automatic reset on power restoration30 AmpEasy Pull
  • Shuts off power when the following is present:
    • NEW! Open Ground
    • Open neutral
    • Low (<102V) and High (>132V) Voltage
  • NEW! Thermal protection against plug and receptacle overheating (Patent Pending)
  • LCD display (English)
  • Multi-mode surge suppression
  • 128 second reset delay protects A/C compressor
  • Continuously monitors and indicates:
    • NEW! Surge Failure
    • Voltage and amp draw (RMS)
    • Reverse polarity (miswired pedestal, elevated ground voltage)
  • 2450 Joules of power surge protection
  • Convenient plug disconnect handles
  • Weather resistant

--------------------------------------------------

50 AMP Surge Guard (Hardwired) - $369.49 (Part Only), $586.12 (Part plus Installation)
120/240V, 3850 Joules, Model 35550

35550

This NEW 50 amp Surge Guard product monitors shore power continuously and shuts off when it detects power surges, open ground, open neutral, low or excessive voltage, miswired pedestals, reverse polarity, or elevated neutral current conditions that could damage electronic equipment in your coach. Like its 30 amp partner, the 50 amp hardwire unit is permanently installed within the bay of your coach, preventing potential theft and damage from the elements. Optional Remote LCD Display conveniently and remotely monitors RV electrical power. Usage

Additional model 35550 features include:

  • Automatic reset on power restoration.
  • Multi-mode surge suppression
  • Automatically shuts off the power when the following is present:
    • Open ground
    • Open neutral
    • Low (<102V) and High (>132V) Voltage
    • Reverse polarity
    • Miswired pedestal
    • High neutral current
  • Caution indicator lights indicate:
    • Elevated ground voltage
    • Surge failure indication128 second reset delay protects A/C compressor.
  • 3850 Joules of power surge protection.
  • Easy installation
  • Optional Remote Power Monitor LCD Display, p/n 40300, (sold separately)
    • Plugs into remote port on Surge Guard model 35550 (see above)
    • Compatible with previous models with a telecom jack.
    • 16 Detailed Fault Screens
    • Joystick for easy screen navigation
    • Plug and Play (cable included)

--------------------------------------------------

50 AMP Portable Surge Guard - $429.49
120/240V, 3850 Joules, Model 34850

34850

The new 50 Amp Surge Guard portable with LCD display offers more than twice the Joules of power surge protection than the previous model. Continuously monitors for voltage and amp draw and reverse polarity (miswired pedestal, elevated ground voltage). Compact and easy to use, they plug in between the power pedestal and the line cord to provide protection. Designed for all travel trailers, 5th wheels and motorhomes with 50 Amp service.

  • Protects RV from faulty park power
  • Built-in intelligence
  • Automatic reset on power restorationEasy PullUsage
  • Shuts off power when the following is present:
    • NEW! Overheating Plug/Receptacle (Patent-Pending)
    • NEW! Open Ground
    • Open neutral
    • Low (<102V) and High (>132V) Voltage
  • LCD display (English)
  • Multi-mode surge suppression
  • 128 second reset delay protects A/C compressor
  • Continuously monitors for:
    • Surge Failure
    • Voltage and amp draw (RMS)
    • Reverse polarity (miswired pedestal, elevated ground voltage)
  • 3850 Joules of power surge protection
  • Convenient plug disconnect handles
  • Weather resistant

--------------------------------------------------

Lock Hasp Surge Guard (34590) - $25.95

Prevents unauthorized removal of your Surge Guard electrical protector from your RV. Easily attaches to standard 30 Amp and 50 Amp plugs. A customer supplied padlock is then attached to the Universal Lock Hasp, eliminating the possibly of unauthorized removal.

34590
